Tignum Elevations

Engineered Wood Ceiling Baffle System

Offers baffles in different widths, lengths and heights to bring added dimension to your ceiling design.

Specifications

Material
Engineered Wood
Weight
.75 - 1.28 lbs./ln.ft
Thickness
1-1/2" up to 3"
Surface Finish
Real Wood Veneer
Seismic Performance
This product has been engineered for use in all seismic areas. Installations may require additional attachments. Check with local code officials or a licensed engineer for additional requirements.
Fire Performance
Can be manufactured Class A: Tested per ASTM E84, CAN/ULC S102 surface burning characteristics.
Applications
Tignum is not approved for exterior applications. Tignum components must be acclimatized prior to installation and installed only after reaching equilibrium moisture content. Relative humidity between 25% and 55% and temperatures between 50˚F and 86˚F must be maintained.
LEED Points
  • LEED BD+C: New Construction v4; MR: Regional Materials; MR: Recycled Content
  • LEED BD+C: Healthcare v4; MR: Design for Flexibility
  • LEED BD+C: New Constructon v4.1; MR: Sourcing of Raw Materials; MR: Bio-based Materials
  • LEED ID+C: Commercial Interiors v4; EQ: Low-Emitting Materials
Declarations
No VOC’S: No added urea – formaldehyde
FSC chain of custody veneers available
Recycled Content
Finishes
42 wood veneers plus any commercially available veneer. 16 standard stains and custom stain matching
Custom Options
Custom sizes & shapes – At Maxxit custom is what we do best. We will make any shape or size you can design.
Standard Options
Furniture grade millwork manufactured in accordance with practices and tolerances of the CISCA Wood Ceiling Technical Guidelines updated July 2020.
In addition to custom we also have quick ship standard products available made to order:
Lengths - up to 8' (nominal)
Depths - 4" - 12"
Widths - 1.5" & 2"
Installation
  • Lightweight, pre-assembled & easy to install
  • Versatile attachment options for Unistrut®, 15/16” HD Grid and cable-suspended applications
  • Easy plenum access – attachment hardware allows baffles to slide for easy plenum access and adjustment during installation
Care & Maintenance
Cleanable using CDC recommended and EPA-approved disinfectants for fog, spray & wipe

Assembly

Material and Finishing Options

  • Walnut

    Wood veneer finish

  • Red Oak

    Wood veneer finish

  • Cherry

    Wood veneer finish

  • White Oak

    Wood veneer finish

  • White Maple

    Wood veneer finish

  • Ash

    Wood veneer finish
